Essential Control for Air Systems
A pneumatic system is only as good as its control. Merely connecting tubes isn’t enough; you need to manage the pressure, direction, and speed of the air. Victory Technology’s Valves & Flow Control Series offers a suite of inline fittings designed to regulate system behavior without the need for bulky, expensive solenoid manifolds.
Explore Our Control Valve Types:
1️⃣ Hand Valves (AHVFF Series – Manual Shut-Off)
-
Function: A manual 2-way or 3-way valve to turn airflow ON or OFF.1
-
Design: Features a 90° rotary handle or lever for quick visual status checks.
-
Application: Essential for safety maintenance, isolating machine sections, or manually venting residual pressure before repairs.2
2️⃣ Check Valves (ALSA Series – One-Way Flow)
-
Function: Allows air to flow in only one direction and blocks it from returning.3
-
Design: Internal spring-loaded mechanism closes instantly if reverse pressure occurs.4
-
Application: Prevents “cross-talk” between air tanks, protects compressors, and maintains vacuum pressure in lifting systems.
3️⃣ Flow Control / Throttle Valves (ASVFF Series – Speed Control)
-
Function: Regulates the volume of air passing through the tube to control actuator speed.5
-
Design: Features a fine-adjust knurled knob and locking nut.
-
Application: Critical for controlling the extension/retraction speed of pneumatic cylinders in automation and robotics.
Why Choose Victory Control Fittings?
-
Push-in Convenience: All valves feature built-in push-to-connect ports for fast installation with PA, PU, or PE tubing.
-
High Reliability: Leak-free seals and durable internal components ensure consistent operation in high-cycle environments.
-
Versatile Mounting: Inline designs save space and reduce weight compared to metal block valves.
🧰 Technical Specifications (Series Overview)
| Feature | Specification |
| Product Series | AHVFF (Hand), ALSA (Check), ASVFF (Throttle) |
| Connection Type | Push-In (Tube-to-Tube or Thread-to-Tube) |
| Tubing Compatibility | 4mm – 16mm (Metric) & Imperial Sizes |
| Thread Options | Metric, BSP (G/R), NPT |
| Body Material | PBT Polymer / Nickel-Plated Brass |
| Working Pressure | 0 – 150 PSI (1.0 MPa) |
| Operating Temp | 0°C to +60°C |
❓ Frequently Asked Questions (FAQ)
Q: What is the difference between a Flow Control Valve and a Hand Valve?
A: A Hand Valve is an ON/OFF switch (fully open or fully closed). A Flow Control Valve acts like a dimmer switch, allowing you to fine-tune the amount of air passing through to adjust speed.6
Q: Do Check Valves reduce air pressure?
A: They have a very slight “cracking pressure” (the minimum force needed to open the spring), but generally, they are designed to minimize pressure drop while flowing in the correct direction.7
Q: Can I use these on truck air brake lines?
A: These are excellent for auxiliary circuits (air seats, horns, door controls) and automation. For primary DOT brake lines, ensure you are using DOT-certified brass fittings where required by law.
📦 Factory Direct Packaging (B2B)
-
Bulk Bags: 50/100 pcs per bag (labeled with Series e.g., “AHVFF-08 Hand Valve”).
-
Protection: Valves are packed in sealed bags to prevent dust ingress.
-
OEM Options: Custom knob colors or body markings available for large orders.
